Полка для хранения 1000х300х2100мм, дополнительная часть

Galvanized steel pipe and steel wire trolley.
The double-level trolley is suitable for use in both shops and warehouses.
The upper level can be raised.
The trolleys can be pushed into each other for storage.
The trolley has four rotating rubber wheels with a diameter of 125 mm.
The external dimensions of the trolley are 1030x530x1020mm.
The carrying capacity of the trolley is 300 kg.
Weight is 22 kg.
The trolley is delivered in parts.

The set includes 1 side frame, 5 shelf plates and shelf carriers.
The shelf plates and side frames are made of galvanized sheet metal.
The side frame consists of two posts, two post soles, connection elements between the posts and fasteners.
The bearing force of each shelf plate is evenly for a distributed load is 150 kg.
The adjustment step of the shelf surface is 50 mm.
The height of the additional part is 2100 mm, the depth is 600 mm.
The exact width of the additional part is 1170 mm.
The additional part is not an independent shelf .
To form a multi-part shelf row, one or more additional parts must be attached to the main part in sequence.
Supplied in parts.

The set includes 1 side frame, 5 shelf plates and shelf carriers.
The shelf plates and side frames are made of galvanized sheet metal.
The side frame consists of two posts, two post soles, connection elements between the posts and fasteners.
The bearing force of each shelf plate is evenly for a distributed load is 200 kg.
The adjustment step of the shelf surface is 50 mm.
The height of the additional part is 2100 mm, the depth is 400 mm.
The exact width of the additional part is 1000 mm.
The additional part is not an independent shelf .
To form a multi-part shelf row, one or more additional parts must be attached to the main part in sequence.
Supplied in parts.

The set includes 2 side frames, 5 shelf plates, 1 back cross and shelf carriers.
The shelf plates and side frames are made of galvanized sheet metal.
The side frame consists of two posts, two post soles, connecting elements between the posts and fasteners.
Each the carrying capacity of the shelf plate for an evenly distributed load is 200 kg.
The adjustment step of the shelf surface is 50 mm.
The height of the main part is 2100 mm, the depth is 800 mm.
The exact width of the main part is 1045 mm.
The main part is independent shelf.
Additional parts with the same depth measurement can be attached to the main part to extend the shelf.
Supplied in parts.

The set includes 2 side frames, 5 shelf plates, 1 back cross and shelf carriers.
The shelf plates and side frames are made of galvanized sheet metal.
The side frame consists of two posts, two post soles, connecting elements between the posts and fasteners.
Each the carrying capacity of the shelf plate for an evenly distributed load is 150 kg.
The adjustment step of the shelf surface is 50 mm.
The height of the main part is 2100 mm, the depth is 600 mm.
The exact width of the main part is 1045 mm.
The main part is independent shelf.
Additional parts with the same depth measurement can be attached to the main part to extend the shelf.
Supplied in parts.
