Toote mõõtmed | 148x101x51cm |
Võimsus | 9kW |
Toitepinge, V | 400 |
Kambri kõrgus | 15cm |
Küpsetusala mõõtmed | 105x70cm |
Maht | 6 x Ø 30/34 |
Neto kaal, kg | 157.2 |
Stainless steel hood, with lighting.
Outlet Ø 200 mm.
For Pyralis and Pyralis-Up 6L and 12L pizza ovens.
Base frame for oven Pyralis or Pyralis-Up 6L.
Manual control panel.
Capacity: 6 x Ø 30/34 (x2) pizzas.
Power: 2x 3.65 kW above and 2x 3.65 kW below.
Chamber height is 15 cm.
Dimensions of the cooking area are 70x105 cm.
Digital control panel.
Capacity: 6 x Ø 30/34 (x2) pizzas.
Power: 2x 5.4 kW above and 2x 3.48 kW below.
Chamber height is 15 cm.
Dimensions of the cooking area are 70x105 cm.
Digital control panel.
Capacity: 9 x Ø 30/34 (x2) pizzas.
Power: 2x 8.1 kW above and 2x 5.22 kW below.
Chamber height is 15 cm.
The dimensions of the cooking area are 105x105 cm.
Manual control panel.
Capacity: 9 x Ø 30/34 pizzas.
Power: 8.1 kW above and 5.22 kW below.
The door opens from the bottom up.
Material: (housing) stainless steel, (interior) galvanized steel.
For 2 x 4 pizzas max.
Ø 30 cm.
Top and bottom heat separately adjustable.
Insulation with rock wool.
Interior lighting and heat-resistant glass windows.
With thermostat and main switch.
High quality pizza oven.
For cleaning we recommend our brass brush (217-1025).
Only clean the fireclay bricks when they are dry and cold, (risk of breakage).
Weight: 142 kg.
Dimensions: W 895mm x T 875mm x H 735mm.
temp.
+50/+450 °C.
Conn.: 400 V - 50 Hz - 10 kW.
