Mõõdud: 585x655x815mm.
Võimsus: 3,12kW / 230V.
Pesuprogramme 4tk - 90/110/120/300sekundit.
Korvi suurus: 500x500mm.
Korvi tunnis - (+55°C) kuni 40tk.
Klaasi maksimum kõrgus 320mm.
Taldriku maksimum kõrgus 350mm.
Paagi kütteelemendi võimsus / mahtuvus 2,6kW - 24L.
Boileri kütteelemendi võimsus / mahtuvus 2,5kW - 7,3L.
Pesupump (kW-Hp) 0,52kW / 0,7Hp.
Soovituslik sissetuleva vee temperatuur +55°C.
Veekaredus 7÷10 °f.
Veekulu ühes tsüklis (soovituslik veesurve 2BAR) 2,0L.
Reguleeritav pesuaine ja loputusvahendi jaotur ELECTRIC.

Very easy in use, cleaning, maintenance and even servicing.
Perfect for washing plates, cutlery, glasses, mugs, trays.
Electromechanical controls.
Housing made of stainless steel AISI 304.
Separate spray arms for washing (plastic) and rinsing (stainless steel).
Fixed washing arms at the top, rotating stainless steel rinsing arms.
Water consumption of only 2-2.5 liter per cycle (depending on water pressure).
Washing water temperature: 62°C, rinse water temperature: 85°C.
Solid double-skin door.
Washing cycles number/duration: 1/120 s.
Capacity: up to 30 baskets/h.
Water consumption per cycle: 2-2,5 l (depending on water pressure).
Washing water temperature: 62°C, rinse water temperature: 85°C.
Boiler (capacity/power): 6 l/3 kW for 230V and 6 kW for 400V.
Tank (capacity/power): 35 l/3,6 kW.
Pump power: 0,75 HP.
Safety thermostat for boiler/for tank up to 105°C/99°C.
Analog water thermometer for boiler.
IP44 protection class.
Weight: 57 kg.

EQUIPMENT:
- 1x universal baskets 500x500x(H)105 mm for glasses
- 1x basket with pins 500x500x(H)105 mm for plates
- 1x cutlery basket 110x110x(H)130 mm
- water supply hose length 1,5 m with connection 3/4” inner thread
- drain hose length 2 m Ø 25 mm
- power cord without plug,
- rinse aid dispenser
- adjusted for detergent pump installation (screw in tank rear wall).

Vertically adjustable legs: ±10 mm, Ø 40 mm.

Very easy in use, cleaning, maintenance and even servicing..
Perfect for washing plates, cutlery, glasses, mugs, trays.
Electromechanical controls.Housing made of stainless steel AISI 304.
Separate spray arms for washing (plastic) and rinsing (stainless steel).
Fixed washing arms at the top, rotating stainless steel rinsing arms.
Solid double-skin door.
Washing cycles number/duration: 1/120 s.Capacity: up to 30 baskets/h.
Water consumption per cycle: 2-2,5 l (depending on water pressure).
Washing water temperature: 62°C, rinse water temperature: 85°C.
Boiler (capacity/power): 6 l/3 kW for 230V and 6 kW for 400V.
Tank (capacity/power): 35 l/2,8 kW.
Pump power: 0,75 HP.
Safety thermostat for boiler/for tank up to 105°C/99°C.
Analog water thermometer for boiler.
IP44 protection class.
Weight: 57 kg.

EQUIPMENT:
- 1x universal baskets 500x500x(H)105 mm for glasses
- 1x basket with pins 500x500x(H)105 mm for plates
- 1x cutlery basket 110x110x(H)130 mm
- water supply hose length 1,5 m with connection 3/4” inner thread
- drain hose length 2 m Ø 25 mm
- power cord without plug,
- rinse aid dispenser
Preparred for detergent pump installation (screw in tank rear wall).

Vertically adjustable legs: ≈10 mm, Ø 40 mm.

Dishwasher for 50x50 baskets.
Upper and lower washing and rinsing arms made of stainless steel, in innovative HydrobladeTM technology, detachable.
Inlet height: 380mm.
Maximum height of washed dish: 380mm.
Ergonomic handle integrated with the door housing.
Safety feature preventing operation with open doors.
5 selectable time options: 90, 110, 120, 180, 240 seconds; corresponding basket capacity per hour for each time: 40, 33, 30, 20, 15.
Boiler capacity/power: 8 l/5 kW; Tub capacity/power: 15 l/1.8 kW.
Rinse pump power: 750W (1HP).
Water consumption per cycle: 2.5 liters.
Adjustable feet up to 1 cm.

Very easy in use, cleaning, maintenance and even servicing..
Perfect for washing plates, cutlery, glasses, mugs, trays.
Electromechanical controls.Housing made of stainless steel AISI 304.
Separate spray arms for washing (plastic) and rinsing (stainless steel).
Fixed washing arms at the top, rotating stainless steel rinsing arms.
Solid double-skin door.
Washing cycles number/duration: 1/120 s.Capacity: up to 30 baskets/h.
Water consumption per cycle: 2-2,5 l (depending on water pressure).
Washing water temperature: 62°C, rinse water temperature: 85°C.
Boiler (capacity/power): 6 l/3 kW for 230V and 6 kW for 400V.
Tank (capacity/power): 35 l/2,8 kW.
Pump power: 0,75 HP.
Safety thermostat for boiler/for tank up to 105°C/99°C.
Analog water thermometer for boiler.
IP44 protection class.
Weight: 57 kg.

EQUIPMENT:
- 1x universal baskets 500x500x(H)105 mm for glasses
- 1x basket with pins 500x500x(H)105 mm for plates
- 1x cutlery basket 110x110x(H)130 mm
- water supply hose length 1,5 m with connection 3/4” inner thread
- drain hose length 2 m Ø 25 mm
- power cord without plug,
- rinse aid dispenser
Preparred for detergent pump installation (screw in tank rear wall).

Vertically adjustable legs: ≈10 mm, Ø 40 mm.
